Model | i-movacMA T | i-movacM T |
High-Pressure Pump (Cleaning Pressure) | 50MPa | |
Pressure Adjustment Method | Smart pressure adjustment system | |
Stroke (mm) | X=700 Y=500 Z=500 | X=700 Y=500 Z=500 |
Maximum Travel Speed | 48m/min (X,Y,Z) | |
Repeat Positioning Accuracy | ±0.05mm | |
Maximum Spindle Speed | 500r/min | |
Tool Magazine Capacity | 6 Units | None (No tool change) |
Specifications | FANUC 0i | |
Filter System | Simple filter (#40) + Bag filter (10μ) + Bag filter (5μ) | |
Standard Configuration Accessories | CNC rotary table, oil-water separator, mist collector, indoor lighting | |
Weight | 6.5Ton | 6.5Ton |
Equipment Dimensions (mm) | Width 2000 × Length 5000 × Height 3000 | Width 2000 × Length 5000 × Height 3000 |
Capacity | 41KVA | |
