Model | i-movacMA (Standard Machine) | i-movacMA-PLUS (New Standard Machine) | i-movacLLA (Large Machine) |
High-Pressure Pump | 50MPaｘ20L/min | ||
Pressure Adjustment Method | Smart pressure adjustment system | ||
Stroke (mm) | X=700 Y=500 Z=500 | X=700 Y=600 Z=500 | X=1000 Y=700 Z=700 |
Maximum Travel Speed | 48m/min (X,Y,Z) | 60m/min (X,Y,Z) | 30m/min (X,Y,Z) |
Repeat Positioning Accuracy | ±0.05mm | ±0.05mm | ±0.08mm |
Maximum Spindle Speed | 500min-1 | 1000min-1 | 500min-1 |
Tool Magazine Capacity | 4 Units (Optional 6 units) | 6 Units | 4 Units ( Optional 6 units) |
CNC Specifications | FANUC 0i MF PLUS | ||
Filter System | imple filter (#40) + Bag filter (10μ) + Bag filter (5μ) | Simple filter (#40) + Bag filter (10μ + 5μ) | Simple filter (#40) + Bag filter (10μ) + Bag filter (5μ) |
Standard Configuration Accessories | CNC rotary table, oil-water separator, mist collector, indoor lighting | ||
Weight | 6.5Ton | 4.9Ton | 8.5Ton |
Equipment Dimensions (mm) | Width 2000 × Length 5000 × Height 3000 | Width 1800 × Length 5000 × Height 2600 | Width 2400 × Length 5200 × Height 3000 |
Capacity | 41KVA | 61.5KVA | 45KVA |
