Model | F22 | i-FW LLA |
High-Pressure Pump (Cleaning Pressure) | 50MPa | 50MPa |
Pressure Adjustment Method | Smart pressure adjustment system | Smart pressure adjustment system |
Stroke (mm) | X=700 Y=550 Z=550 | X=1000 Y=500 Z=700 |
Maximum Travel Speed | 48m/min | 38m/min |
Maximum Spindle Speed | 500min-1 | 500min-1 |
High-pressure Nozzle Quantity | 2 Units (Optional 4 units) | 4 Units (Optional 8 units) |
Low-pressure Nozzle | 1Set (rotary) | 1Set |
CNC Specifications | FANUC 31i | FANUC OI MF PLUS |
Filter System | Cartridge filter (#50) + Bag filter (10μ) + Bag filter (5μ) | Paper belt filtration / Magnetic roller separation (Optional)+Bag filter |
Accessories (Optional) | Chip conveyor, oil-water separator, mist collector, indoor lighting, vacuum dryer | Air Blow Spindle, Air Blow Nozzle |
Weight | 8.5T | 10T |
Electrical Capacity | 84KVA | 51KVA |
Air Blow Spindle, Air Blow Nozzle | / | 500L |
Filling and Drainage Time | / | 30s |
